The firmware can be a life saver sometimes. If your device gets bricked because of a bad installation of app or any mod, then you can use the firmware to go back to stock easily. It’s also helpful in removing the root and TWRP recovery from your device, and install the stock recovery back.
Some of you may be looking for a Note 5 Oreo firmware, but well, sorry to be the bearer of bad news: Note 5 isn’t supported with Android 8.0 update by Samsung. Thus, you won’t see Oreo update for the Note 5, and thus no firmware either.
You have to install firmware meant for the exact model no. of your device, so check out that first before downloading the firmware. Check out the sections below to identify model no. of your handset, and a way to install the firmware given in the table below for various model no. of the Note 5.
Check the above link for latest news on Note 5 update, with their changelog. You might want to check out which update (and firmware) brings fixes of major security issues.
Samsung Galaxy Note 5 Firmware
Some of the Galaxy Note 5 models are as follows based on the carrier or region.
- AT&T Galaxy Note 5: SM-N920A
- T-Mobile Galaxy Note 5: SM-N920T
- Sprint Galaxy Note 5: SM-N920P
- Verizon Galaxy Note 5: SM-N920V
- US Cellular Galaxy Note 5: SM-N920R4
- Canadian Galaxy Note 5: SM-N920W8
- Global Galaxy Note 5: SM-N920G/H/i/F/FD
AT&T Note 5 firmware:
Here are some AT&T Note 5 firmwares, because they are not included in the table below. Find the firmware for others models and carriers in the table below.
- Android 7.0 – N920AUCU4EQC6
- Android 6.0.1 – N920AUCS4CQB2
- Android 6.0 – N920AUCS4CPK1
- Android 6.0 – N920AUCS3CPJ1
- Android 6.0 – N920AUCS3BPH4
- Android 5.1.1 – N920AUCU2APB2
How to download correct firmware file
This is the important part!
Be sure to check and find the correct the model no. of your Galaxy Note 5. Then based on your device’s model no., look for the appropriate firmware build from above.
You can identify the model no. using an app called Droid Info, or simply check it on its packaging box, or under Settings > About. Another solid trick would be to look at the packaging box of your device (in case you can’t power on the device because it is bricked).
Now that you know the model no., download the latest firmware from above for that model no. exactly.
Next, install the firmware on your Galaxy Note 5 by following the guide linked right below.
How to Install Firmware
First, read our disclaimer, then take backup and then follow the guide below to install the firmware.
Disclaimer: Installing an official firmware through Odin doesn’t void your device’s warranty, but it remains an unofficial process and thus you need to be cautious of it. In any case, you only are responsible for your device. We won’t be liable if any damage occurs to your device and/or its components.
Backup, backup, backup! Create an appropriate backup of contacts, pictures, videos, songs and other important files stored on your device before proceeding with the steps below, so that in case something goes wrong you’ll have a backup of all your important files. Sometimes, firmware installation may delete everything on your device! Like, when you change the CSC of your device, knowingly or not.
Step-by-step Firmware Installation Guide
Let’s see how to install the firmware on your Galaxy Note 5. Make sure you have more than 30% battery on your device.
Step 1. Make sure you have downloaded the correct firmware file on your PC. See above for how to download correct firmware file for your Galaxy Note 5 and download links.
Step 2. Install Samsung USB driver (method 1 on the linked page) first of all. Double click the .exe file of drivers to begin the installation. (Not required if you have already done this.)
Step 3. Also, download Odin PC software (latest version).
Step 4. Extract the firmware file now. You can use a free software like 7-zip for this. Install 7-zip, then right click on firmware file and under 7-zip, select ‘Extract here’. You should get a file in .tar.md5 format now. (You may get 4 or more files, with AP, BL, CP or CSC etc. written at the beginning of those files.) We will be loading this file into Odin, to be installed on device (in step 10 below).
Step 5. Extract the Odin file. You should get the Odin exe file (other files could be hidden, hence not visible).
Step 6. Disconnect your Galaxy Note 5 from PC if it is connected.
Step 7. Boot into download mode:
- Power off your device. Wait for 6-7 seconds after screen goes off.
- Press and hold the three buttons Volume down + Home + Power together until you see Warning screen.
- Press Volume Up to continue to download mode.
Step 8. Double click on Odin .exe file (from step 5) to open the Odin window as shown below. Be careful with Odin, and do just as said to prevent problems.
Step 9. Connect your device now using USB cable. Odin should recognize your device. It’s a must. When it recognizes, you will see Added!! message appearing in the Log box in bottom left, and the first box under ID:COM will also show a no. and turn its background blue. Look at the pic below.
- You cannot proceed until you get the Added!! message, which confirms that Odin has recognized your device.
- If you don’t get Added!! message, you need to install/re-install drivers again, and use the original cable that came with device. Mostly, drivers are the problem (look at step 2 above).
- You can try different USB ports on your PC too.
Step 10. Load the firmware file into Odin. Click the AP button on Odin and the select the .tar.md5 file from above.
Load the firmware files(s) on your device. This depends on how many files you got in step 4 above upon extracting the firmware .zip file.
Case 1: If you got a single .tar/.tar.md5 file, then load this into AP tab of your Odin software. Then go to next step.
To load the file, click on AP tab, select the single firmware file starting with AP text, wait for it to load, and then skip to step 11, ignoring the rest of the part of this step.
Case 2: If you got more than one .tar/.tar.md5 file, then you must be having files starting with AP, CSC, Home_CSC, BL, CP, etc. stuff. In this case, choose the files as following. Select the firmware files as follows.
- Click on BL tab, and select the file beginning with BL text.
- Click on AP tab, and select the file beginning with AP text.
- Click on CP tab, and select the file beginning with CP text.
- [Different] Click on CSC tab, and select the file beginning with HOME_CSC text. If HOME_CSC file isn’t available, then select the file beginning with CSC text.
About CSC file: Using the HOME_CSC file won’t reset your device, and data on the phone shouldn’t be deleted. However, when we select regular CSC file, and it results in CSC on device being different than that in CSC file, your phone will be formatted automatically. You can even choose to ignore loading the CSC file, that may do alright too. But if it doesn’t works out, repeat the whole process and select CSC file this time around.
- Info: When you load files, Odin checks the md5 of firmware file, which takes time. So, simply wait until that’s done and the firmware file is loaded. Don’t worry if Odin gets unresponsive for a while, it’s normal. Binary size will also show up in Odin.
Step 11. Click on Options tab, and make sure Re-partition check box is NOT selected. Don’t use PIT tab, ever.
Go back to Log tab now, as it will show the progress of firmware installation when you hit start button in next step.
Step 12. Verify that everything is okay as mentioned above. When satisfied, click the Startbutton on Odin now to start flashing the firmware on your device.
Wait till installation is finished, after which your device will reboot automatically. You’ll get PASS message as shown below upon successful installation from Odin.
Some errors you may run into, and with respective solution.
- If Odin gets stuck at setup connection, then you need to do this all again. Disconnect your device, close Odin, boot device into download mode again, open Odin, and then select the file and flash it again as said above.
- If you get FAIL in the top left box, then also you need to flash the file again as stated just above.
That’s it. Let device restart automatically.
First start of the device may take time, so wait patiently again. When it has, verify the installation. Check the Settings > About device, to confirm new build no. based on the firmware you just installed.
Need help? Sure let us know via comments below.
Firmware Benefits
You can use the firmware for variety of purposes, which includes:
- Fix your Galaxy Note 5 if it’s giving you force closes errors and restarts randomly.
- Unbrick your Galaxy Note 5 if it’s bootlooping and stuck at logo when restarting.
- Go Back to Stock on your Galaxy Note 5 — helps when looking to sell the device, or fix installing OTA updates if broken.
- Restore Galaxy Note 5 to factory state.
- Upgrade your Galaxy Note 5 to newer Android version.
- Downgrade your Galaxy Note 5 to lower build no. at same Android version.
- Unroot your Galaxy Note 5.
- Remove custom recovery like TWRP and CWM, if installed, on your Galaxy Note 5.
To perform any of the above, simply install the firmware meant for your device, as per its Galaxy Note 5 firmware in Settings > About device.
